Description
FIRMWARE TARGET : FURYF4OSD (LEGACY)
Mamba F405 Mini FC MK2
Item name: F405 mini Betaflight Flight Controller
Input: 2~6 S LIPO (7.4V~24V)
BEC: 5V 2A
MCU: STM32F405
Gyro: MPU6000
FLASH: 16M
OSD: AT7456
Mounting Hole: M3
Weight: 3.5g
MAMBA F30 MINI Dshot600 4IN1 ESC 30A 5S
INPUT VOLTAGE: 2~5 S Lipo
CONTINUE CURRENT: 30A×4 BURST CURRENT: 40A (10S) BEC: NO MOUNTING: 20×20mm,⌀ 2
Supply : Rubycon High Frequency 470uF/35V
CONTINUE CURRENT: 30A×4 BURST CURRENT: 40A (10S) BEC: NO MOUNTING: 20×20mm,⌀ 2
Supply : Rubycon High Frequency 470uF/35V
Parameters
ESC firmware | BLHeli 32 |
BEC | 5V/2A |
FC CPU | STM32F405 |
DJI HD support | no |
OSD | yes |
Mounting pattern | 20x20 mm (micro) |
IMU | MPU6000 |
Steady current | 30 A |
voltage | 3-5 cell (11.1V-18.5V) |
Mamba F405 Mini FC MK2 | |
Item name | F405 mini Betaflight Flight Controller |
Input | 2~6 S LIPO (7.4V~24V) |
BEC | 5V 2A |
MCU | STM32F405 |
Gyro | MPU6000 |
FLASH | 16M |
OSD | AT7456 |
Mounting Hole | M3 |
Weight | 3.5g |
MAMBA F30 MINI Dshot600 4IN1 ESC 30A 5S | |
INPUT VOLTAGE | 2~5 S Lipo |
CONTINUE CURRENT | 30A×4 |
BURST CURRENT | 40A (10S) |
BEC | NO |
MOUNTING | 20×20mm,⌀ 2 |
Supply | Rubycon High Frequency 470uF/35V |
Package contents
1 x Mamba F4 Mini Betaflight Flight Controller
1 x Mamba F30MINI HV ESC
Reviews

1 rating





Write a review!
Samuele Vinti
|

Verified purchase
13/04/2021
Despite the 1mm FC pad, it was super easy to solder the other components to it.
The box is full of accessories for all kind of mount-style.
Came flashed with BF 4.2
The box is full of accessories for all kind of mount-style.
Came flashed with BF 4.2
